APG Machine with 22t Clamp Force and 1000X1000mm Clamp Plate Size for 900900900 Specification Epoxy Resin Machine

Model NO. : 001

Phase : Three

Operation Condition : Outdoor

Usage : Protection, Measurement

Winding Form : Multilayer Honeycomb Type

Insulating Medium : Epoxy Resin

Installation : Active Type

Magnetic Circuit Structure : Combined Type

Voltage Transformation Principle : Photoelectric Type

Clamp Plate Size : 1000X1000mm

Clamp Force : 22t

Min Max Clamp Plate Strok : 250X1650mm

250X1650mm : 900X400mm

Heating Power : 36kw

Transport Package : Wooden

Specification : 900*900*900

Trademark : JC

Origin : China

HS Code : 8514300090

Production Capacity : 60000PCS/Year

MOQ : 1

Price : 3000

Contact Now

APG Machine = Automatic pressure gel equipment
APG machine with Epoxy Resin for Electric Insulation of 38KV Outdoor Transformer CT and PT.

Ithasbeen nineteen ye arsold and hasbeen developing into DMC after continuous development. S hydraulic press, epoxy resin pressure gel forming machine, full automatic Epoxy Static system and metal extrusion hydraulic press and other equipment, and can design and manufacture various kinds of special equipment according to the needs of high-voltage electrical appliances users.

Servo HAPG Clamping Machine
This machine is full automatic, Servo and Pic touch screen control Machine, the clamp plate size n customized, greatly improved efficiency and product quality Advantages

Servo motor control
PLC touch screen control
Can save more than 100product datas
Fully automatic design

Auto start machine heating clamp plate Auto setting hydraulic pressure Auto setting heating temperature Auto setting valve flow
APG Machine with 22t Clamp Force and 1000X1000mm Clamp Plate Size for 900*900*900 Specification Epoxy Resin Machine

APG Machine with 22t Clamp Force and 1000X1000mm Clamp Plate Size for 900*900*900 Specification Epoxy Resin Machine

Machine Technical Parameters

Model no	HMI-1200
clamp plate size	1000X1000mm
clamp force	22T
Min Max clamp plate strok	250X1650mm
Upper &lower core puller stroke	900X400mm
Heating power	36KW
ydraulic power pack	7.5KW
Horizontal tilting angle	0-5
mould load weight	4T
Machine weight	9200KG
Machine dimension	5200^1400X3700mm
